Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine

1 / 4

Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine

Send Inquiry

Product Description

⚙️ Small size high power high rpm 12v 24v gear motor for vacuum cleaner, cordless power tools, and sewing machines.

📋 Product Description

PMDC MOTOR TECHNICAL DATA
Model	Rated Voltage(V)		No-Load		Rated				Stall
	Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
	Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-550H	23128R	6.0~24.0	24VDC	4500	0.1	3932	0.39	25.7/262	10.6	4.8	204/2080
RS-550H	6034	6.0~12.0	12VDC	16000	1.12	13613	4.96	25.6/261.3	40.36	48.89	281.4/2870
RS-555H	3540	6.0~12.0	12VDC	7800	0.3	6708	1.84	21.9/223.4	15.35	11.31	156/1591
RS-555H	23100	6.0~24.0	24VDC	7000	0.14	6004	0.77	19.2/195.8	12.09	4.2	124.5/1270

🚀 Application

⭐ Customer Evaluation

📜 Certifications

💡 Recommend Products

❓ FAQ

🔹 1. Are you a trading company or manufacturer?

We are a factory specializing in micro DC motors and DC gear motors for more than 14 years.

🔹 2. What is the payment term for new customers?

We accept various payment methods including online assurance orders (MasterCard, Visa), PayPal, and TT.

🔹 3. Can you customize a motor if I can't find a suitable one?

Yes, we can customize a suitable motor according to our customer's specific technical requirements.

🔹 4. Do you have certificates for the motors?

Yes, we have CE, FCC, ISO, and other relevant certificates. We can apply for additional certifications if required.

🔹 5. How is your Quality Control?

We have professional inspectors for every production stage. Finished motors undergo rigorous testing using hardness testers, 2.5D image testers, salt spray chambers, life testers, and noise testers.

🔹 6. What is the typical lead time for orders?

Lead times vary depending on the order volume and customization requirements, but we strive to maintain efficient production cycles for all clients.
