Small Electric Motor M20 Dc Motor 1.5v 3v Micro Dc Motor for home appliance

Product Description

Product Promotion

Small Electric Motor M20
Micro DC Motor
DC Motor Series
📝

Product Description

Motor Dimension
PMDC MOTOR Technical Data
Model Voltage (V) No-Load Rated Stall
Operating Range Nominal Speed (RPM) Current (mA) Speed (RPM) Current (mA) Torque (mN.m) Power (W) Current (mA) Torque (mN.m)
FF-M20VA 8130 2.0~3.0 3VDC 15200 45 11800 160 0.16 0.19 550 0.69
7170 1.5-3.0 2VDC 8000 25 6000 75 0.09 0.06 230 0.35
10100 1.5~4.0 2.8VDC 18000 50 14800 190 0.2 0.3 880 1.1
🚀

Product Application

Application Scenarios
🏢

Our Company

Factory Overview
Our company was established in 2005. It's a high-tech enterprise integrating the research, development, production and sales of various kinds of micro DC motor, geared motor, planetary geared motor, shade pole geared motor and special gearbox motor. Products are widely used in automobiles, communications equipment, smart home, medical equipment, intelligent security, household appliances, western kitchen equipment, machinery and electronics and other high-end transmission structures, products are exported to more than 50 countries and regions at home and abroad.
⚙️

Production Process

Production Line
🏆

Certifications & Quality

Certificates
Advanced Equipment
Our company has introduced dozens of advanced production equipment and testing instruments from Germany, Japan, Switzerland and other countries to strictly control the quality of each motor.
Testing Instruments

Frequently Asked Questions

Are you a trading company or a manufacturer?
We are a factory specializing in micro DC motors and DC gear motors for more than 14 years.
What are the payment terms for new customers?
We can facilitate online assurance orders, which accept Master Card, Visa, etc. Payments via PayPal or TT are also accepted.
Can you customize a motor for my specific requirements?
Yes, we can customize a suitable motor according to our customer's technical requirements and specifications.
Do you have certifications for your motors?
Yes, we have CE, FCC, ISO, and other relevant certifications. We can apply for additional certificates if required.
How do you ensure quality control?
We have professional inspection staff at every production stage. Finished motors undergo comprehensive testing using equipment such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, and Noise Testers.
What is the typical lead time for orders?
Lead times depend on the specific motor model and order quantity. Please contact us with your requirements for a detailed production schedule.
